Hikrobot 25MP Area Scan Camera, GigE,Mono，F-mount,with fan MV-CH250-21GM-F-NF
- Resolution of 5120 × 5120 and pixel size of 4.5 μm × 4.5 μm.
- Adopts GigE interface providing max. transmission distance of 100 meters without relay.
- Adopts local memory for burst transmission and retransmission.
- Compact design with mounting holes on the up and bottom panels for flexible mounting.
- Compatible with GigE Vision V2.0 Protocol, GenlCam Standard, and the third-party software based on these protocol and standard.
Ihr dynamisches Snippet wird hier angezeigt ...
Diese Meldung wird angezeigt, weil Sie weder einen Filter noch eine Vorlage zur Verwendung bereitgestellt haben.
Technische Daten
| Auflösung | 5120 × 5120 |
| Schnittstelle zur Datenübertragung | Gigabit Ethernet, compatible with Fast Ethernet |
| Sensortyp | CMOS |
| Binning | Supports 1 × 1, 2 × 2, 4 × 4 |
| Decimation | Supports 1 × 1, 2 × 2 |
| Reverse Image | Supports horizontal and vertical reverse image output |
| Model Number | MV-CH250-21GM-F-NF |
| Sensor Model | OnSemi PYTHON25K |
| Pixel Size | 4.5 μm × 4.5 μm |
| Sensor Size | 23 mm × 23 mm |
| Max Frame Rate | 4.64 fps @5120 × 5120 |
| Mono/Color | Mono |
| Lens Mount | F-mount, optical back focal length 46.5 mm (1.8") |
| Exposure Mode | Off/Once/Continuous exposure mode |
| Certification | CE, RoHS, KC |
| Pixel Format | Mono 8/10/10p/12/12p |
| Digital I/O | 12-pin Hirose connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2), RS-232 × 1, and RS-485 × 1 |
| Power Supply | 12 VDC |
| Power Consumption | 6.7 W |
| Dimension | F-mount with fan: 74 mm × |
| Ingress Protection | IP40 |
| Storage Temperature | -30 °C to 70 °C |
| Humidity | 20% to 95% RH, non-condensing |
| Client Software | MVS or third-party software meeting with GigE Vision Protocol |
| Operating System | 32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS |
